DIMENSIONS
Length: 116 in. Width: 36 in. Height: 22 in.
WEIGHT
330 lbs
FRAME
Chassis: Dual Layer Nomex Honeycomb Core Material
Carbon Fiber: Stiff Support
Kevlar: Outer Skin / Insulation
Mono Shock Setup -
Work Performance Shocks
- Front: Modified Dual A-Arm
- Rear: Swing Arm: Dual Wheel
Array Substructure
- Fiberglass - Carbon Fiber
Solectra DC Brush Type
Permanent Magnet Motor
- 85% Efficiency
- Rated Power: 3hp
- Maximum Power: 12hp
8 GNB EV-500 lead-acid 12 Volt
3.4 Wh discharge at 5hrs
34.5 per battery
20 inch ACS brand BMX Tires at 100 psi
Brakes: Primary and Secondary Hydraulic Disk Brakes
Speed Control: Average speed: 25-30 mph Top speed: 40 mph
Average efficiency is 14.25% of sunlight
converted to energy
- 14.5% efficient polycrystalline solar cells
- 14% efficient monocrystalline solar cells
